EnducTrace - Traceable Conduit

EnducTrace is a premium HDPE, Outside Plant Smoothwall Conduit with a factory installed tracer wire for easy, one step installation of conduit and tracer together.


BENEFITS:

  • Reduced labor costs - eliminate need for separate wire in trench
  • Steel Tracer is durable, lighter than copper
  • Can be Directionally bored into place
  • Two Strong tape layers for long lasting installation
  • Wire is external to conduit therefore NO interference with fittings or fusion
  • Conduit wall is not compromised
  • Available most sizes of conduit

TRACER WIRE SPECIFICATIONS:

  • 10 awg standard
  • Single Strand Copper Clad Steel by Copperhead
  • Break Load - 600 lbs.
  • Insulation type - HDPE
  • Total Weight of 10 awg tracer wire = 32.5 lbs./1000 feet
  • Meets national Plumbing Code 2.6.6.1 for tracer wire

TAPE SPECIFICATIONS:

  • Two, independent, sprial wound, polypropylene tape layers encase the wire and hold it to the conduit
  • Will NOT interfere with fittings or fusion connections
